FM51

Combat Vehicle Mask

The FM51 is a variation of the latest generation Avon Protection FM50 mask, but designed specifically for combat vehicle operators by enabling vehicle respiratory and communications system integration.

The FM51 is designed specifically for combat vehicle operators. Supported with a CVC hood for head and neck protection and a communications lead and hose to integrate with the vehicle’s blower and COLPRO systems, the FM51 provides the same outstanding protection from battlefield concentrations of CB agents, toxic industrial materials, chemicals and particulates.

The FM51 offers vehicle operators clear communications while wearing a mask; and an integrated Electronic Communications Port allows for direct connection to the vehicle’s radio system though low profile communications lead.

Twin filters reduce breathing resistance and Avon Protection’s advanced hose assembly provides direct interface with the vehicle’s air supply with a quick release connection for rapid exit.

Suitable for:

  • First Responders
  • Military

The FM51 is designed specifically for combat vehicle operators. Supported with a CVC hood for head and neck protection and a communications lead and hose to integrate with the vehicle’s blower and COLPRO systems, the FM51 provides the same outstanding protection from battlefield concentrations of CB agents, toxic industrial materials, chemicals and particulates.

The FM51 offers vehicle operators clear communications while wearing a mask; and an integrated Electronic Communications Port allows for direct connection to the vehicle’s radio system though low profile communications lead.

Twin filters reduce breathing resistance and Avon Protection’s advanced hose assembly provides direct interface with the vehicle’s air supply with a quick release connection for rapid exit.

Features and Benefits

Field of View

  • Panoramic single lens visor
  • Optically correct visor
  • Scratch Resistant

Comfort

  • Chlorobutyl rubber silicone blend mask
  • 3 face piece sizes for improved fit
  • High flow fail safe drinking device

Communications

  • Front mounted exhale valve allows clear direct communication
  • Electronic Communication Port (ECP) for optional voice projection
  • Radio communications available through ECP

Air Management

  • Low inhalation resistance & excellent de-mist properties
  • Low-re-breathed carbon dioxide
  • Hose assembly provides rapid interface to vehicle air supply

Technical Specifications

Technical Data
CBRN Agent ResistanceFM51 Performance

Mustard (H)

Greater than 36 hrs

Sarin (GB)

Soman (GD)

VX

Laboratory Protection

Greater than 10,000

Factory Performance

(Sodium Chloride)

Weight

FM51 mask (including twin filters)

860g (1.9 lbs)

FM51 mask (including twin filters, vehicle hose, protective hood, and comms lead)

1270g (2.8 lbs)

Breathing Performance

Re-breathed CO2

0.80%

Inhalation Resistance at:

Mask Only:

Mask & Filters:

30 L/Min

2 mm WG

10 mm WG

95 L/Min

8 mm WG

30 mm WG

160 L/Min

12 mm WG

64 mm WG

(with FM61 filters fitted)

Exhalation Resistance at:



85 L/Min

7mm WG

160 L/Min

12 mm WG

Field of View

Visual Field Score - NIOSH CBRN APR Standard

96

NIOSH CBRN Cap 1 Requirements

Resources and Downloads

Accessory Data Sheets

Product Literature

Technical Documents

Accessories

Individual Equipment CarrierComplimentary to the Mask Carrier and provides additional storage of antidotes and first aid equipment. Designed with MOLLE attachment, it offers multiple mounting options and flexible storage options.
